Specifications:
TECH DATA
Signal System HDV: 1080/60i
DVCAM/DV: 480/60i (NTSC)
Image Device 1/4" 3CMOS ClearVid Sensor
Lens Carl Zeiss Vario-Sonnar T* Zoom Lens, 20x (Optical),
Signal-to-Noise Ratio Not Specified by Manufacturer
Horizontal Resolution 1080 Lines
Sensitivity Not Specified by Manufacturer
Minimum Illumination 4 Lux f1.6 at 18 dB
Vertical Smear Not Specified by Manufacturer
Built-in Filters 1/4 ND, 1/16 ND
LCD Monitor Clear Photo LCD Plus, 3.5", 16:9 Aspect Ratio
Viewfinder 0.44", 252,000 Pixels, 16:9 Aspect Ratio
Scan Matching Yes
Memory Card Slot No
Shutter Speed Range 60i: 1/4, 1/8, 1/15, 1/30, 1/60, 1/90, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/725, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/6000, 1/10000
24p: 1/3, 1/6, 1/12, 1/24, 1/40, 1/48, 1/50, 1/60, 1/96, 1/100, 1/120, 1/144, 1/192, 1/200, 1/288, 1/400, 1/576, 1/1200, 1/2400, 1/4800, 1/10000 sec
Gain Selection 0, 3, 6, 9, 12, 15, 18 dB
VTR
Tape Format DVCAM Small Cassette
HDV Record and Play
DVCAM Record and Play
DV Record and Play
Tape Speed HDV: 18.8 mm/s
DVCAM: 28.2 mm/s
DV SP Mode: 18.8 mm/s
Signal-to-Noise Ratio Not Specified by Manufacturer
Maximum Recording Time HDV: 63 min (with PHDVM-63DM Cassette)
DVCAM: 41 min (with PHDVM-63DM Cassette)
DV: 63 min (with PHDVM-63DM Cassette)
Audio
Audio Dynamic Range Not Specified by Manufacturer
Audio Signal Format HDV
MPEG1 Audio Layer II
DVCAM/DV
16-bit/48kHz 2 Channel Mode
12-bit/32kHz 4 Channel Mode
Audio Frequency Response 20Hz to 20kHz
Signal to Noise Ratio Not Specified by Manufacturer
General
Input and Output Connectors Composite Vide RCA (x1 Output, A/V Out 10-pin Connector Jack)
Component Video (x1 Output)
HDV/DV I/O: i.LINK FireWire Interface
Audi XLR 3-Pin (x1 Input)
Headphones: Stereo Mini Jack
LANC: Stereo Mini-mini (2.5mm) Jack
USB: Mini-B Connector
HDMI Output: HDMI Connector
Power Requirements 7.2 VDC
Power Consumption HDV: 6.8W
DVCAM/DV: 6.6W
Operating Temperature 32-104°F (0-40°C)
Dimensions (WxHxD) Not Specified By Manufacturer
Weight 3.4 lb (1.5 kg)
